HD12
The HD12 is a discontinued digital-to-analog converter with coaxial, optical and USB inputs, balanced XLR and unbalanced RCA outputs, and a headphone output. It suits listeners who want to bring an existing system up to a higher digital standard.
- USB-B input up to 24 bit / 192 kHz
- Native DSD64 playback over USB (PC only)
- 1 coaxial and 2 optical digital inputs
- Balanced XLR and unbalanced RCA outputs
- Headphone output and remote-controlled volume
- Noise floor -145 dB; 2.5 V RMS output
Fotos
8Anzeigen
Noch keine Anzeigen für dieses Modell
Wenn jemand ein HD12 verkauft, erscheinen hier die Anzeigen und der Verkaufsverlauf.
So eins verkaufenBeschreibung
The HD12 converts digital audio from a computer or a source with a digital output into analog signal. Its USB-B input handles all common sample rates up to 24 bit / 192 kHz and plays native DSD64 files without conversion to PCM (PC only). The two optical inputs and the coaxial input are described as being of equal quality.
On the analog side it provides balanced XLR outputs, unbalanced RCA outputs and a headphone output. A built-in volume attenuator with remote control lets it feed active loudspeakers or a power amplifier directly, as well as a receiver, amplifier or subwoofer. The converter uses a 32 bit DAC and digital filter, a linear-phase analog filter, and a stated noise floor of -145 dB.
Power comes from an internal toroidal transformer with 20,000 μF capacitors. The unit measures 6 x 21 x 26 cm and weighs 3.5 kg. The HD12 now appears in the maker's discontinued range.
Video
Technische Daten
- Marke
- Hegel
- Modell
- HD12
- Kategorie
- Hi-Fi und Heimaudio › Sonstiges Hi-Fi
Inputs
- Digital inputs
- 1 coaxial, 2 optical and 1 USB-B (2.0)
- Coaxial/optical resolution
- Up to 24 bit/192 kHz
- USB resolution
- Up to 24 bit/192 kHz
- DSD capability
- DSD64
Outputs
- Analog outputs
- XLR balanced and RCA/phono unbalanced/headphone
- Output signal level
- 2.5 V RMS (at 0 dBFS)
- Volume control
- Built-in, remote-controlled attenuator
Audio
- DAC IC/digital filter
- 32 bit
- Frequency response
- 0 Hz - 50 kHz
- Phase response
- Linear phase analog filter
- Noise floor
- -145 dB
- Distortion
- Typically less than 0.0005%
Power
- Power supply
- Internal toroidal transformer and 20,000 μF capacitors
Physical
- Height
- 6 cm (2.35")
- Width
- 21 cm (8.3")
- Depth
- 26 cm (10.24")
- Weight
- 3.5 kg (6.6 lbs)
