H190
Integrated amplifier with built-in DAC and network streaming (DLNA and AirPlay), rated at 2 x 150 W into 8 Ω. Aimed at listeners who want a single-box amplifier for demanding loudspeakers, with a front headphone output. It is now listed as a discontinued model.
- 2 x 150 W into 8 Ω, stable down to 2 Ω
- Built-in DAC with DLNA and AirPlay streaming
- Damping factor above 4000
- Front-facing 6.3 mm headphone output
- XLR and RCA analog, plus coaxial, optical, USB inputs
- Anodised aluminium case in black or white
Fotos
8Anzeigen
Noch keine Anzeigen für dieses Modell
Wenn jemand ein H190 verkauft, erscheinen hier die Anzeigen und der Verkaufsverlauf.
So eins verkaufenBeschreibung
The H190 is an integrated amplifier that combines a power stage, a DAC and a network streamer in one chassis. Its SoundEngine2 error-canceling amplifier delivers 2 x 150 W into 8 Ω and works down to a 2 Ω minimum load. A damping factor above 4000 on the main output stage lets it control large loudspeakers.
Streaming is handled over the network via DLNA and AirPlay, so music from streaming platforms can be sent to it directly. Digital inputs cover coaxial, optical and USB as well as network, and the analog side offers one balanced XLR and two unbalanced RCA inputs. The inputs are configurable. A 6.3 mm headphone output sits on the front panel, and an OLED display shows status.
For connecting to other equipment, there are two unbalanced RCA line outputs, one fixed and one variable. The casing is anodised aluminium, offered in black or white, and the unit runs on 100/120/230 V AC mains.
Video
Technische Daten
- Marke
- Hegel
- Modell
- H190
- Kategorie
- Hi-Fi und Heimaudio › Verstärker
Inputs
- Analog inputs
- 1 x balanced (XLR), 2 x unbalanced (RCA)
- Digital inputs
- 1 x coaxial (RCA), 3 x optical, 1 x USB, 1 x Network
Outputs
- Power output
- 2 x 150 W into 8 Ω @ 1kHz 1% THD
- Minimum load
- 2 Ω
- Line level output
- 1 x unbalanced fixed (RCA), 1 x unbalanced variable (RCA)
- Headphone output
- 6.3 mm, front-facing
Connectivity
- Streaming
- DLNA, AirPlay
- Network input
- 1 x Network
Audio
- Frequency response
- 5 Hz - 100 kHz
- Signal-to-noise ratio
- More than 100 dB
- Crosstalk
- Less than -100 dB
- Distortion
- Less than 0.01% @ 25 W/8 Ω/1 kHz
- Intermodulation
- Less than 0.01% (19 kHz + 20 kHz)
- Damping factor
- More than 4000 (main power output stage)
- Amplifier technology
- SoundEngine2
Power
- Mains voltage
- 100/120/230V AC
Physical
- Dimensions incl. feet (HxWxD)
- 12 cm x 43 cm x 41 cm
- Dimensions (US, HxWxD)
- 4.72" x 16.93" x 16.15"
- Weight
- 17 kg (37.5 lbs)
- Finish
- Black or White
- Display
- OLED
